PH
Occlusion:
flat face
Locking:
lever with safety devices
Material:
steel、aluminum alloy
Finishing:
Zn-Fe (Cr III) / Zn-Ni / Anodizing
Threads:
BSP – NPT – SAE –METRIC
Standard seals:
NBR,PU
Working temperature:
-25 °C to +100 °C
Optional seals:
FKM, EPDM or more
Working pressure:
250-350 bar
Connection under pressure:
allowed to be connected with residual pressure,it”s not allowed to disconnect with residual pressure.
Max residual pressure:
100bar
Features
Low Oil Leakage
The flat valve leaks very little during disconnecting and connecting, reducing the losses of oil in the hydraulic circuit.
Easy Cleaning & Anti-pollution
The flat valve is easy to clean and reduces pollution to the hydraulic circuit.
Mechanical Locking Protection
Mechanical locking avoids mechanical wear and brinelling of ball locking.
Safety Lock Design
Safety lock prevents accidental disconnection.
Flexiblility & Versatility
Flexible and versatile to meet different customer needs.
Technical data
| Nominal Size | Working Pressure | Rated Flow(ISO) | Max flow Rate | Burst Pressure | Fluid Spillage | |||
| Male | Female | Coupled | ||||||
| FH/PH | ISO | Mpa | 1/min | 1/min | Mpa | Mpa | Mpa | cc |
| FH10/PH | 10 | 35 | 23 | 46 | 160 | 140 | 170 | 0.012 |
| FH12/PH | 12.5 | 35 | 45 | 90 | 140 | 140 | 170 | 0.02 |
| FH16/PH | 16 | 35 | 74 | 148 | 140 | 140 | 170 | 0.026 |
| FH19/PH | 19 | 35 | 100 | 200 | 130 | 120 | 140 | 0.03 |
| FH25/PH | 25 | 35 | 189 | 378 | 100 | 100 | 110 | 0.035 |
Appllication
