RF
Occlusion:
flat face
Locking::
screw
Material:
steel,brass
Finishing:
Zn-Ni
Threads:
BSP – NPT – UNF
Standard seals:
HNBR
Working temperature:
-40 °C to +150 °C
Optional seals:
PU, FKM, EPDM or more
Working pressure:
350 bar
Connection under pressure:
allowed
Max residual pressure:
30bar
Features
Low Pressure Drop & High System Efficiency
The internal design of the valve and the use of high-strength materials help to achieve a minimum pressure drop and improve system efficiency.
Low Oil Leakage
The flat valve leaks very little during disconnecting and connecting, reducingf the losses of oil in the hydraulic circuit.
Easy Cleaning & Anti-pollution
The flat valve is easy to clean and reduces pollution to the hydraulic circuit.
Threaded Locking Protection
Threaded locking can prevent mechanical wear and brinelling caused by steel ball locking.
Technical data
| Nominal Size | Working Pressure | Rated Flow （ISO） | Max Flow Rate | Burst pressure | Fluid Spillage | |||
| Male | Female | Coupled | ||||||
| RF | ISO | Mpa | 1/min | 1/min | Mpa | Mpa | Mpa | cc |
| RF06 | 6.3 | Mpa | 12 | 25 | 180 | 120 | 200 | 0.06 |
| RF10 | 10 | Mpa | 23 | 46 | 160 | 140 | 170 | 0.012 |
| RF16 | 16 | Mpa | 74 | 148 | 140 | 140 | 170 | 0.026 |
| RF19 | 19 | Mpa | 100 | 200 | 130 | 120 | 140 | 0.03 |
Appllication
